Piranha Series
2014 - 2021

The Piranha is everything you need for scooter diving! It is the lightest, most powerful dive scooter we could build; and to maximize utility for both technical and recreational divers we have made it modular. With neutrally buoyant battery modules you can build and dive the scooter you need. The Piranha comes neutrally weighted and balanced for both salt and fresh water, and includes an integrated GoPro camera mount, as well as the ability to upload data from your scooter to your Windows PC using an additional link cable. Designed and assembled in the USA.

Piranha P1

SCOOTER SPECIFICATIONS:
Weight: 24.6lbs (11.1kg)
Length: 19in (48.2cm)
Depth Rating: 600ft (182.8m)
Thrust: 73lbs (324.7N)
Max Speed: 268ft/min (81.6m)
Range @ Max Speed: 1.2 miles (1.9km)
Runtime @ Max Speed: 24 min
Cruise Range (150ft/min): 3.5 miles (5.6km)
Runtime @ Cruise Speed: 122 min

BATTERY SPECIFICATIONS:
Battery Chemistry: Li-Ion
Battery Voltage: 36V (from x4 PTBs)
Battery Capacity: 400Wh 10Ah (from x4 PTBs)
Charger: See PTB charger (typically 110/240V)
Charge Time: See PTB charger (typically 1-3 hours)

Piranha P2

SCOOTER SPECIFICATIONS:
Weight: 34lbs (15.4kg)
Length: 24.1in (61.2cm)
Depth Rating: 600ft (182.8m)
Thrust: 73lbs (324.7N)
Max Speed: 268ft/min (81.6m)
Range @ Max Speed: 2.5 miles (4km)
Runtime @ Max Speed: 51 min
Cruise Range (150ft/min): 7.3 miles (11.7km)
Runtime @ Cruise Speed: 257 min

BATTERY SPECIFICATIONS:
Battery Chemistry: Li-Ion
Battery Voltage: 36V (from x8 PTBs)
Battery Capacity: 400Wh 10Ah (from x8 PTBs)
Charger: See PTB charger (typically 110/240V)
Charge Time: See PTB charger (typically 1-3 hours)

Piranha P3

SCOOTER SPECIFICATIONS:
Weight: 41lbs (18.5kg)
Length: 29.2 (74.1cm)
Depth Rating: 600ft (182.8m)
Thrust: 73lbs (324.7N)
Max Speed: 268ft/min (81.6m)
Range @ Max Speed: 3.8 miles (6.1km)
Runtime @ Max Speed: 77 min
Cruise Range (150ft/min): 11.1 miles (17.8km)
Runtime @ Cruise Speed: 392 min

BATTERY SPECIFICATIONS:
Battery Chemistry: Li-Ion
Battery Voltage: 36V (from x12 PTBs)
Battery Capacity: 400Wh 10Ah (from x12 PTBs)
Charger: See PTB charger (typically 110/240V)
Charge Time: See PTB charger (typically 1-3 hours)

USEFUL LINKS:
Piranha Scooter Features
Piranha User Manual
Piranha Diagrams

Compatible with 5Ah, 20v (USA only) or 18v batteries that fit the DCB interface.

TESTED WITH THE FOLLOWING BATTERIES:
4 x Enegitech 20V 5.0Ah Lithium Battery
4 x Batteriol 20V 5.0Ah Lithium Battery
4 x DeWalt DCB205 (USA) 20v Max 5.0Ah
4 x DeWalt DCB184 18v XR
